New Presentation from Objective by the Sea 2.0 - Watching the Watchers

Just got back from a wonderful time hanging out with the who’s who of Mac security folk in swanky Monaco at the Objective by the Sea conference. I’ve uploaded my presentation Watching the Watchers in my Resources section. This presentation goes through some of the forensically useful artifacts of the following 3rd party monitoring software:

Direct link to the presentation here.

I cannot recommend enough that the OBTS conference is absolutely worth going to if you are at all involved in Apple Security. Next one is ~Q1 2020 and back in Maui!

AirDrop Analysis of the UDP (Unsolicited Dick Pic)

I saw this article “NYC plans to make AirDropping dick pics a crime” on Friday and it got me thinking. What exactly are the cops going to find if they do an analysis of a device, either the sender or the receiver?

I’ve already done my fair share of analysis when it comes to the Continuity technology with Apple devices with Heather Mahalik at the SANS DFIR Summit in 2017. This article gave me a good reason to do a revisit on how AirDrop artifacts between mobile devices.

Testing Scenario

I’m using the scenario of sending of dick pics in the middle of Times Square as an example. I have two test phones, an iPhone 7 and an iPhone 6. The iPhone 7 belongs to “David Lightman” and the iPhone 6 belongs to “Jen Mack”.  Each device is on iOS 11 for this test. Instead of UDPs, Jen is going to be sending David USP’s instead, or Unsolicited Squirrel Pics – I suppose I need to keep this family friendly right?

AirDrop works over ad-hoc Peer-to-Peer networking over Bluetooth and Wi-Fi. When a user attempts to AirDrop someone a file it will determine who is within range and who is currently receiving AirDrop connections. This may be set to Contacts Only or Everyone (or Receiving Off for those who don’t want UDP’s, smart choice). Poor David has the setting to Everyone, he’ll get some surprises!

To send the squirrel photo to David, Jen used the native Photos application’s sharing feature to select a device to AirDrop the USP to. The only device within range that has AirDrop turned on and in a receiving mode is David Lightman’s iPhone.

Jen selects his phone and sends the picture. On David’s device he receives a pop-up, he can choose to Decline or Accept.

AirDrop ID

Important to this analysis is an AirDrop ID. On devices this can be found in /private/var/mobile/Library/Preferences/com.apple.sharingd.plist. The keyword ‘sharingd’ is very important in this scenario as much of the Continuity artifacts can be found by searching for that process name. This plist file should be available in an iTunes backup and from any commercial forensic utility.

Jen’s AirDrop ID is 3DAA769F9F23.

David’s AirDrop ID is E7D713098E3B, also take note of that the DiscoverableMode is set to Everyone. (Jen does not have this key, hers was set Contacts only.)

Artifacts from the Receiver’s (David Lightman) Device

Assuming that the receiver is the individual who would likely make the complaint to the cops, we will look at this iPhone first to determine what artifacts will persist and if they are show attribution to a certain device and/or owner.

Very few artifacts on the devices will actually show this connection happening. Let’s take a look at some of the main artifacts that I would explore if I had the case.

Unified Logs

Logs can show lots of data and in great verbose detail. Unfortunately, these Unified Logs do not get backed up on iOS devices. The only way to extract them from the device is to get a physical file dump of the device (Jailbreak/Cellebrite CAS/GrayKey). (UPDATE: 12/04/18 - It has come to my attention from a commentor that these unified log files can be collected using the sysdiagnose process on iOS devices. I’ve tested this and they are in fact there. Funny enough, per Apple Documentation, it wants you to copy this archive off the device using AirDrop. 🤷🏻‍♀️ Not entirely the most forensically sound method but hey, data is data - get it with whatever means your legal team will allow. Thanks ‘G’!)

In this example on David’s iPhone, you can see the sharingd process start to scan, attempting to find peers (Continuity connections). During this process you will also see lots of wirelessproxd and bluetoothd activity as well since AirDrop uses Bluetooth and Wi-Fi services. You will also see references to AWDL or Apple Wireless Direct Link.

Follow the logs down a bit and you’ll start to run into some potentially identifying information. We are now starting to see records containing Jen’s device name “Jen Mack’s iPhone”. Pay close attention to the first record highlighted and you’ll see what looks like a MAC address, however it is neither the Bluetooth nor the Wi-Fi addresses. This address is generated different every time a connection is made, therefore not an ideal data point for attribution.

Going back to the device’s name. This may lead you in the right direction, however anyone can name their device anything they want. I can call my iPhone X “Samsung S9” for instance, no identifying information and frankly a device that doesn’t even do AirDrop.

The next couple of highlighted sections (in red), show the start of the AirDrop connection. We can see an incoming request and start seeing records that include the AirDrop ID of Jen’s iPhone, 3DAA769F9F23. This is where I think attribution may be possible. This ID seems consistent across connections and different devices in my experience. It may be possible to tie this to an Apple ID or specific device. I have yet to find this connection however – it’s not part of the Serial, UDID, or various MAC addresses that I can tell. More research is needed here.

Next, in purple, is more metadata about the file transfer to include transfer status, media type, originating device name, source application, and associated transfer GUID.

In between these metadata records, it shows that it is transferring a file to /var/mobile/Downloads/com.apple.AirDrop/BA40D8CF-54E6-4B09-8F2F-717FB638174E/Files. Whether the user chooses Accept or Decline, the photo still gets transferred to the device.

Finally, the user receives an alert about the AirDrop’ed photo. Following this record is more details on how the user is alerted to the connection audibly and physically with alert tones and vibrations.

This particular AirDrop connect was “Declined” by David. This can be seen in the records below where the ‘selectedAction’ now shows Decline and a clean-up process has started. Highlighted in teal is the AirDrop connection closing.

If the user Accepted the AirDrop’ed photo, the logs would look like the following. The file would have been ‘accepted’ in the metadata records. Finally, since it is a photo – the default application Photos wants to import it into its files and databases. The AirDrop connection is also closed at this time.

Photos Database

Since the photo gets transferred into the user’s Photos database we can look there for hints. This is one file that does get backed up by iTunes and commercial forensic utilities. The Photos database is located /private/var/mobile/Media/PhotoData/Photos.sqlite on the physical device.

The filename on Jen’s device was IMG_0007.JPG before it got renamed to IMG_0110.JPG on David’s phone. The original filename can be found in the ZADDITIONALASSETATTRIBUTES table in the ZORIGINALFILENAME column.

It is worth noting that the imported photo will carry the same EXIF data as the original on Jen’s device, in fact it is exactly the same photo (hashes should match). The file size and some timestamps get carried over into the Photos database. Other metadata items can be used to determine a photo from another device are the Height/Width, assuming it is from a different family of devices the pixels may be different.

In the ZGENERICASSET table, we have the same Height/Width, however some timestamps are updated to match the time of import via AirDrop. The ZDATECREATED timestamp matches the original creation of the photo. The ZCLOUDASSETGUID matches the GUID seen in the last few entries in the logs above. There does not appear to be any attribution data in this database.

Artifacts from the Sender’s (Jen Mack) Device

In the rare event that the Sender’s device was acquired, the related artifacts are below.

Unified Logs

Much of the logs look similar to the receiver. The sample below shows the sharingd process connecting to David’s AirDrop ID, E7D713098E3B and shows his iPhone device name. Again, the MAC address does not appear to be consistent and will change on every connection.

A few more lines down we can see some file conversion for the photo, IMG_0007.JPG (which apparently wasn’t needed). This is followed by an AirDrop transaction with the AirDrop ID of David’s iPhone.

Conclusion

The lack of attribution artifacts at this time (additional research pending) is going to make it very difficult to attribute AirDrop misuse. At best, if the cops are provided each device, they can pair the connections up – however this will require access to file system dumping services like Cellebrite CAS, GrayKey from GrayShift or performing a jailbreak to get the most accurate analysis. If the devices are named appropriately (ie: If Jen Mack’s iPhone was actually named ‘Jen Mack’s iPhone’) this may make an analysis easy, however I can see an instance where this can be abused to imitate someone else.

Curious about the USP, here you go. This was an advertisement in the DC Metro system, that for some reason whenever I saw it I giggled. 🤷🏻‍♀️

Slides and Script! From Apple Seeds to Apple Pie & Introducing APOLLO: The Apple Pattern of Life Lazy Output'er

I had the privilege and honor to present at the first ever Objective by the Sea Mac Security Conference yesterday in Maui (hardship, right?). It was only the first day and it was absolutely spectacular, I may have to make this one a regular! I can easily recommend attending this conference.

I presented From Apple Seeds to Apple Pie - an Apple Pattern of Life talk (mostly focused on iOS devices). You can find the slides in my Resources section.

I also just released a (very) beta version of APOLLO (Apple Pattern of Life Lazy Output’er) on my GitHub page. The TL;DR of the script: Take all the creepy databases that Apple writes events to, perform individual SQL queries on them to pull out investigative useful data, and combine them into another SQLite database for easier/quicker analysis and correlation.

This script and its modules are still in the testing phases so please be careful when using this on real cases. Expect more modules and testing to be released, I’m holding some back due to some timestamp issues and other are partially written up.

Ok Internet, Lets Test this APFS Plaintext Password Bug Properly

There has been some confusion (myself included) on what is vulnerable to this bug and what isn't. Some folks can replicate and some cannot - so I think its high time to test this properly to see what versions and scenarios are affected by this bug.

The table below is sorted by macOS version - I'm just testing 10.13.x here. (If you happen to get it to leak the password on 10.12.x please let me know.) I'm also organizing by disk formatting scenario since I believe this is where most of the confusion comes from.

APFS encrypted volumes can be created on the disk level as well as the volume level and it truly seems to make a difference. Please also test if you find (or don't find) the results in the Unified logs and/or the install.log or neither (and god forbid any other locations you might come across!). I'm also consistently using the "Erase" button versus the "Partition" button.

If I am missing a certain scenario that you think should be added please let me know. If you disagree with the current findings - also let me know (I will also expect screenshots/videos from you to be sure we're on the same page.) I have tested 10.3.3 (host system) and 10.13.4 (VM) but would love someone to sanity check me - I've been wrong in the past!) I would have done more testing on different versions but have a limited set of systems as I'm traveling right now.

I will update the spreadsheet below as necessary.

For previous related blogs see here and here.

YAY TEAMWORK!

pay attention to me cat GIF-source.gif

OMG, Seriously? - APFS Encrypted Plaintext Password found in ANOTHER (More Persistent!) macOS Log File

UPDATE: PLEASE HELP ME TEST

At some point you just need to stop looking and be blissfully ignorant...this was not one of those days.

In and update to my previously updated blog article, I have found another instance where the plaintext password was written to system logs. This time I found it in more persistent log. This is actually a worse problem than the one I previously reported on.

The previous examples were found in the unified logs which can hang around for a few weeks, this new example stores the exact same information in the system's /var/log/install.log. I have found that the install.log will only get wiped out upon major re-installation (ie: 10.11 -> 10.12 -> 10.13), therefore these plaintext passwords will hang around for quite a bit longer than a few weeks!  I had entries dating back to when I originally installed High Sierra on this system back in November of 2017!

Twitter user @sirkkalap, was unable to re-create what I previously reported on. I finally got some time this afternoon to re-test. As it turns out, I was unable to re-create my results from 03/24. I assumed that at some point in the past few days a silent security update was pushed out. I went to my install.log file to investigate further. As far as updates go - the only thing that has potential to be the cause of the fix is a GateKeeper ConfigData update v138 (com.apple.pkg.GatekeeperConfigData.16U1432). I have not investigated if this was the true cause. I have not updated to 10.13.4 yet, this was on 10.13.3.

During this investigations I was VERY surprised to see the same diskmanagementd logs that I had found in the unified logs. Why are they logged in the software installation log at all, I have no clue. It makes absolutely no sense to me.
